for electronic components, Which applied in multiple fields such as ceramic circuit boards, fuel cells, semiconductors, sensors, touch screens, medical devices,etc
We produce six types of
Micron-Grade Thick Film Screen Printer
including desktop screen printer, flat substrate screen printer, multi-layer structure screen printer, circular tube and rod screen printer and fully automatic screen printer.
Why to choose us
We are an innovative technology enterprise that focuses on the R&D, production, and customization of high-precision thick film screen printer. The products are suitable for thick film screen printing technology in multiple precision electronic industries such as ceramic circuit boards, semiconductors, sensors,power batteries,solar cells,touch screens, Leds, optical lenses,etc.
Since its establishment in 2010, we have always adhered to technological innovation and have formed a full industry intelligent automation thick film printing product system that combines more than 40 patented technologies with more than 30 application models.
Our factory covers an area of 2500 square meters, including a thick film printing laboratory. We have a professional team that continuously develops flat, circular tube, specialized, and automated thick film printing technologies.
Thick film screen printing machines are widely used for surface, buried, through hole printing and production processes of precision electronic components in various industries such as thick film circuits, fuel cells, LTCC, HTCC, MLCC, filters, chip resistors, GPS dielectric antennas, ceramic heating pads, ceramic substrates, chip capacitors, thick film resistors, semiconductors, sensors, flexible electronics, solar cells, etc. The substrate can be various materials such as graphite, ceramics, metals, thin films, wafers, glass, or plastics.
Max Printing size: 100mmx100mm Operation mode: Manual This is a small and high-precision manual desk thick film screen printer that can be used for experimental research on ceramic substrates, small electronic components, etc
Maximum printing size: 200mmx200mm The printing accuracy: ± 5um The screen printer can be used for precision screen printing of ceramic substrates, electronic components,sensor ,PCB boards and other fields. It is equipped with CCD automatic visual alignment to reduce manual feeding errors.
Maximum printing size: 130mmx130mm The printing accuracy: ± 5um This is the special screen printer for Production of Multilayer circuit Components such as LTCC,HTCC,MLCC, fuel cell,solar cell,etc. The platform is equipped with a special roll paper platform, effectively preventing cross contamination during printing.
Maximum printing size: 230mmx230mm The printing accuracy: ± 5um IC-250 upgraded version This is the special screen printer for Production of Multilayer circuit Components such as LTCC,HTCC,MLCC, fuel cell,solar cell,etc. The platform is equipped with a special roll paper platform, effectively preventing cross contamination during printing.
Substrate: ceramics base copper-clad laminates printing accuracy : ± 0.01mm Printing capacity: 600pcs per hour This fully automatic screen printer can be used for the automatic screen printing process of ceramics base copper-clad laminates such as AMB,DBC,etc.
The positioning accuracy of thick film printer is ± 0.005mm, the film thickness deviation is ± 0.004mm, and the 0.02mm width line can printable with electronic paste.
Non-standardized automation solutions according to customer process requirements
Design and produce a fully automatic printing system that includes multiple functions such as automatic feeding, automatic alignment printing, automatic detection, automatic sintering, and automatic material collection,etc. You can also customize the semi-automatic screen printer.
Thick film screen printing technology is widely used in semiconductor production, which can be applied to multiple semiconductor production processes such as round crystal coated glass powder, photoresist printing, soldering printing in semiconductor packaging processes
The application of thick film screen printing technology in the field of medical equipment, such as household medical equipment, high-precision medical testing equipment, etc
